Cables may be used in power stations, industry and switchgear as well as for urban supply networks, where with low risk of mechanical damage. Suitable for Installation indoors, cable trunking, outdoors and buried in the ground and in duct.
Conductor : Copper or Aluminum Class 2 stranded conductors
Insulation: Polyvinyl chloride PVC
Armor: Steel wire or Steel-tape
Over sheath: Polyvinyl chloride PVC or PE
IEC 60228, IEC 60502-1
|
LV Power Cables - Copper Conductor IEC 60502-1 |
||
|
PVC Insulated Cable |
VV (NYY) |
CU/PVC/PVC |
|
VY (NY2Y) |
CU/PVC/PE |
|
|
VV22 (NYBY) |
CU/PVC/STA/PVC |
|
|
VV23 (NYB2Y) |
CU/PVC/STA/PE |
|
|
VV32 (NYRY) |
CU/PVC/SWA/PVC |
|
|
VV33 (NYR2Y) |
CU/PVC/SWA/PE |
|
|
LV Power Cables - Aluminum Conductor IEC 60502-1 |
||
|
PVC Insulated Cable |
VLV (NAYY) |
AL/PVC/PVC |
|
VLY (NAY2Y) |
AL/PVC/PE |
|
|
VLV22 (NAYBY) |
AL/PVC/STA/PVC |
|
|
VLV23 (NAYB2Y) |
AL/PVC/STA/PE |
|
|
VLV32 (NAYRY) |
AL/PVC/SWA/PVC |
|
|
VLV33 (NAYR2Y) |
AL/PVC/SWA/PE |
|
|
Conductor dimensions (mm2) |
Insulation thickness (mm) |
Nonmetallic sheath, unarmored cable |
|||||||||||||||||||
|
Sheath thickness |
Outer diameter (approximate) |
Cable weight (Kg/km) |
|||||||||||||||||||
|
mm |
mm |
Copper core |
Aluminum core |
||||||||||||||||||
|
1C |
2C |
3C |
4C |
5C |
1C |
2C |
3C |
4C |
5C |
1C |
2C |
3C |
4C |
5C |
1C |
2C |
3C |
4C |
5C |
||
|
1.5 |
0.8 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
5.8 |
10.4 |
10.8 |
11.6 |
12.4 |
49 |
131 |
152 |
184 |
215 |
40 |
113 |
124 |
147 |
168 |
|
2.5 |
0.8 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
6.2 |
11.2 |
11.7 |
12.6 |
13.5 |
62 |
159 |
191 |
234 |
277 |
47 |
128 |
144 |
172 |
199 |
|
4 |
1.0 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
7.1 |
12.9 |
13.6 |
14.7 |
15.9 |
86 |
211 |
264 |
330 |
391 |
62 |
161 |
189 |
231 |
266 |
|
6 |
1.0 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
7.6 |
13.9 |
14.7 |
15.9 |
17.3 |
110 |
268 |
334 |
423 |
505 |
73 |
193 |
221 |
273 |
318 |
|
10 |
1.0 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
8.7 |
16.2 |
17.1 |
18.6 |
20.3 |
158 |
380 |
492 |
627 |
754 |
96 |
254 |
303 |
375 |
439 |
|
16 |
1.0 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
9.8 |
18.4 |
19.5 |
21.3 |
23.3 |
224 |
533 |
714 |
905 |
1094 |
124 |
331 |
412 |
502 |
590 |
|
25 |
1.2 |
1.4 |
1.8 |
1.8 |
1.8 |
1.8 |
11.2 |
21.2 |
22.5 |
24.7 |
27.1 |
325 |
759 |
1019 |
1307 |
1592 |
169 |
445 |
547 |
678 |
806 |
|
35 |
1.2 |
1.4 |
1.8 |
1.8 |
1.8 |
1.9 |
12.4 |
23.6 |
21.4 |
27.6 |
30.5 |
429 |
974 |
1313 |
1699 |
2098 |
211 |
533 |
652 |
818 |
997 |
|
50 |
1.4 |
1.4 |
1.8 |
1.8 |
1.9 |
2.1 |
14.0 |
26.8 |
28.0 |
31.6 |
35.2 |
590 |
1265 |
1781 |
2354 |
2929 |
278 |
636 |
837 |
1096 |
1355 |
|
70 |
1.4 |
1.4 |
1.9 |
2.0 |
2.1 |
2.2 |
15.6 |
23.4 |
27.2 |
31.5 |
37.9 |
791 |
1650 |
2393 |
3155 |
3942 |
353 |
770 |
1071 |
1394 |
1740 |
|
95 |
1.6 |
1.5 |
2.0 |
2.1 |
2.2 |
2.4 |
17.9 |
27.2 |
31.4 |
36.6 |
43.0 |
1062 |
2206 |
3205 |
4239 |
5295 |
467 |
1011 |
1412 |
1849 |
2307 |
|
120 |
1.6 |
1.5 |
2.1 |
2.2 |
2.4 |
2.5 |
19.3 |
29.8 |
34.3 |
39.2 |
46.9 |
1306 |
2727 |
3966 |
5244 |
6549 |
555 |
1217 |
1701 |
2224 |
2774 |
|
150 |
1.8 |
1.6 |
2.2 |
2.3 |
2.5 |
2.7 |
21.4 |
32.6 |
37.9 |
43.1 |
52.4 |
1625 |
3374 |
4924 |
6508 |
8155 |
686 |
1486 |
2093 |
2733 |
3437 |
|
185 |
2.0 |
1.7 |
2.4 |
2.5 |
2.7 |
2.9 |
23.7 |
38.6 |
42.3 |
48.2 |
60.7 |
1998 |
4185 |
6062 |
8022 |
10074 |
840 |
1857 |
2571 |
3366 |
4254 |
|
240 |
2.2 |
1.8 |
2.6 |
2.7 |
2.9 |
3.1 |
26.5 |
43.8 |
49.7 |
55.7 |
65.8 |
2565 |
5371 |
7825 |
10335 |
12911 |
1062 |
2351 |
3296 |
4295 |
5361 |
|
300 |
2.4 |
1.9 |
2.7 |
2.9 |
3.1 |
3.3 |
29.3 |
48.8 |
52.8 |
62.3 |
71.4 |
3186 |
6641 |
9696 |
12859 |
16023 |
1306 |
2854 |
4016 |
5285 |
6557 |
|
400 |
2.6 |
2.0 |
|
3.1 |
3.4 |
3.7 |
33.0 |
|
59.8 |
71.2 |
83.1 |
4191 |
|
12739 |
16940 |
21124 |
1684 |
|
5165 |
6842 |
8501 |
|
500 |
2.8 |
2.1 |
|
3.4 |
3.4 |
|
36.4 |
|
74.2 |
82.2 |
86.5 |
5198 |
|
15898 |
20937 |
|
2064 |
|
6431 |
8314 |
|
|
630 |
2.8 |
2.2 |
|
|
|
|
40.1 |
|
77.0 |
85.3 |
|
6464 |
|
|
|
|
2515 |
|
|
|
|
|
800 |
2.8 |
2.3 |
|
|
|
|
45.2 |
|
|
|
|
8126 |
|
|
|
|
3112 |
|
