Aluminum clad steel wire strand

ACS--Aluminum Clad Steel Wire(Alumoweld)

Description

Aluminum clad steel wire is perfectly combined posed of aluminum and steel core, and there will be no flaking off during the heat treatment or mechanical workout. The aluminum clad steel wire is the best new bimetallic wire instead of pure copper wire.
A high strength steel wire with a 25% thick cross-section ratio of aluminum cladding creates a high electrical conductivity, highly corrosive resistant, and a thermal stability for high temperature operation and all with a lighter weight.


Application
It is widely used in long-span transmission line, coastal areas and island as well as other hot and humid regions, salt fog regions and heavily polluted regions where the high corrosion resistance strand is needed.
It is used as the core of ACSR/AW,overhead ground conductor, extra high voltage overhead conductor, optical fiber composite overhead ground line, self-damping conductor line, bare overhead conductor, OPGW , ground wire , messenger wire , guy wire formed wire for protecting , terminating and splicing transmission and distribution lines , fence , barber wire and hardware etc.


Construction
Aluminum clad steel wire is a kind of bimetallic wire that aluminum covers on the steel core continuously and evenly.
Compared with ordinary aluminum cable steel reinforced, the conductor weight is 5% lighter, current-carrying capacity is 2-3% higher and power loss decreases 4-6%. Thus, the service life is long and it adds none erection cost.


Standard
ASTM B416, DIN 48201



ACS / Alumoweld

ALUMINUM CLAD STEEL STRAND ASTM B416

Code Number

Area
mm2

No. of wires

Diameters (mm)

Weight
kg/km

Rated Strength
kN

DC Resistance
ohm/km

wire

conductor

3 No 5 Awg.

50,32

3

4,62

9,96

334,1

54,42

1.6990

3 No 6 Awg.

39 ,00

3

4,11

8,87

265,0

45,74

2.1420

3 No 7 Awg.

31,65

3

3,67

7,90

210,1

38,36

2.7010

3 No 8 Awg.

25,10

3

3,26

7,03

166,7

32,06

3.4060

3 No 9 Awg.

19,90

3

2,91

6,26

132,2

25,43

4.2940

3 No 10 Awg.

15,78

3

2,59

5,58

104,8

20,16

5.4150

7 No 5 Awg.

117,40

7

4,62

13,90

781,1

120,27

0,7426

7 No 6 Awg.

93,10

7

4,11

12,40

619,5

101,14

0,9198

7 No 7 Awg.

73,87

7

3,67

11,00

491,1

84,81

1.1600

7 No 8 Awg.

58,56

7

3,26

9,78

389,6

70,88

1.4630

7 No 9 Awg.

46,44

7

2,91

8,71

308,9

56,20

1.8440

7 No 10 Awg.

36,83

7

2,59

7,76

245,1

44,58

2.3250

7 No 11 Awg.

29,21

7

2,30

6,91

194,4

35,35

2.9320

7 No 12 Awg.

23,16

7

2,05

6,16

154,2

28,03

3.6970

19 No 5 Awg.

318,70

19

4,62

23,10

2129,0

326,39

0,2698

19 No 6 Awg.

252,70

19

4,11

20,60

1688,0

274,55

0,3402

19 No 7 Awg.

200,40

19

3,67

18,30

1339,0

230,18

0,4290

19 No 8 Awg.

158,90

19

3,26

16,30

1062,0

192,41

0,5409

19 No 9 Awg.

126,10

19

2,91

14,50

842,0

152,58

0,6821

19 No 10 Awg.

99,96

19

2,59

12,90

667,7

121,00

0,8601

37 No 5 Awg.

620,60

37

4,62

32,30

4170,0

635,43

0,1394

37 No 6 Awg.

492,20

37

4,11

28,80

3307,0

534,85

0,1757

37 No 7 Awg.

390,30

37

3,67

25,70

2623,0

448,09

0,2216

37 No 8 Awg.

309,50

37

3,26

22,90

2080,0

374,67

0,2794

37 No 9 Awg.

245,50

37

2,91

20,30

1649,0

279,11

0,3523

37 No 10 Awg.

194,70

37

2,59

17,90

1308,0

235,61

0,4443


ALUMINUM CLAD STEEL STRAND DIN 48201

Code Number
mm2

Area
mm2

No. of wires

Diameters (mm)

Weight
kg/km

Rated Strength
kN

DC Resistance
ohm/km

wire

conductor

25

24.25

7

2.1

6.3

162

31.56

3.546

35

34.36

7

2.5

7.5

229

44.72

2.499

50

49.48

7

3

9

330

64.4

1.736

70

65.81

19

2.1

10.5

441

85.65

1.313

95

93.27

19

2.5

12.5

626

121.39

0.925

120

116.99

19

2.8

14

785

152.26

0.737

150

147.11

37

2.25

15.7

990

191.46

0.587

185

181.62

37

2.5

17.5

1221

236.38

0.476

240

242.54

61

2.25

20.2

1635

299.05

0.357

300

299.43

61

2.5

22.5

2017

369.2

0.289
